CAU - Miscellaneous Cabinets
CBU - Cluster Bombs
CCU/CCK - Cartridges
CDU - Clustering Devices
CGU - Cargo Tiedown Items
CHU - Cushions
CKU - Aircraft Ejection Seat Catapults
CLU - Calibrating Items
CMU/CMK - Miscellaneous Clothing
CNU/CNK - Containers
CPU/CPK - Computers
CQU - Breathing Air Items
CRU/CRK - Oxygen Items
CSU/CSK - Special Clothing
CTU - Aerial Delivery Containers
CVU/CVK - Covers
CWU - Warmth Clothing
CXU - Impact Marking Smoke Charges

CAU - Miscellaneous Cabinets

(1...32) (No information)
CAU-33/A

CBU - Cluster Bombs

Notes about extended CBU listing:

CBU-1/A

The CBU-1( )/A anti-personnel cluster bomb consisted of BLU-4( )/B fragmentation bomblets in an SUU-7( )/A dispenser. Known variants include:

No information about the components of the CBU-1A/A is available.

CBU-2/A

The CBU-2( )/A anti-personnel/anti-material cluster bomb consisted of BLU-3/B fragmentation bomblets in an SUU-7( )/A dispenser. Known variants include:

No information about the components of the CBU-2A/A and -2C/A is available. The CBU-8( )/A and CBU-9( )/A dummy clusters were variants of the CBU-2( )/A.

CBU-3/A

The CBU-3( )/A 300 kg (660 lb) anti-tank cluster bomb consisted of BLU-7( )/B bomblets in an SUU-10( )/A dispenser. Known variants include:

(4) (No information)
CBU-5/B

CBU-5/B was the USAF designation for the U.S. Army's 340 kg (750 lb) class M43 non-lethal chemical warfare cluster bomb. The M43 consisted of 57 M138 4.5 kg (10 lb) bomblets in an M30 cluster adapter. The M138 was filled with the BZ hallucinogen for use as an incapacitant agent. However, the effects of BZ turned out to be too unpredictable for use as a weapon, and therefore the substance (and any munitions containing it) were abandoned.

Data for M30:
Length: 2.3 m (7 ft 6 in)
Diameter: 41.4 cm (16.3 in)

Drawings: via ORDATA Online Website
M30 cluster adapter
(6) (No information; possibly related to CBU-13/A)
CBU-7/A

The CBU-7( )/A anti-personnel cluster bomb consisted of 1200 BLU-18/B fragmentation bomblets in an SUU-13( )/A dispenser. Known variants include:

CBU-8/A

The CBU-8( )/A 390 kg (860 lb) cluster bomb was similar to the CBU-2( )/A, and consisted of BDU-27/B spotting charges in an SUU-7( )/A dispenser. Known variants include:

  • CBU-8/A: 409 BDU-27/B in SUU-7A/A
  • CBU-8A/A

No information about the components of the CBU-8A/A is available.

CBU-9/A

The CBU-9( )/A 390 kg (860 lb) dummy cluster bomb was similar to the CBU-2( )/A, and consisted of BDU-28/B dummy fragmentation bomblets in an SUU-7( )/A dispenser. Known variants include:

No information about the components of the CBU-9B/A is available.

CBU-10/B

The CBU-10/B dummy cluster bomb consisted of a U.S. Navy MK 5 MOD 0 "Sadeye" dispenser (typically used with small anti-personnel fragmentation bomblets) filled with BDU-30/B practice bomblets.

Data for MK 5 MOD 0:
Length: 2.4 m (7.8 ft)
Diameter: 40.6 cm (16 in)

Drawing: via ORDATA Online Website
Dispenser MK 5 MOD 0
CBU-11/A
CBU-12/A
CBU-13/A

The CBU-11/A, CBU-12( )/A and CBU-13/A smoke cluster bombs all consisted of 261 BLU-16/B and/or BLU-17/B smoke bomblets in an SUU-7( )/A dispenser. Known variants include:

CBU-14/A

The CBU-14( )/A anti-personnel/anti-material cluster bomb consisted of an unknown number of BLU-3/B fragmentation bomblets in an SUU-14( )/A dispenser. Known variants include:

CBU-15/A

The CBU-15/A was a 340 kg (750 lb) class chemical warfare cluster bomb, which consisted of an unknown number of BLU-19/B23 GB bomblets in an SUU-13/A dispenser.

CBU-16/A

The CBU-16( )/A was a 340 kg (750 lb) class non-lethal chemical warfare cluster bomb, which consisted of an unknown number of BLU-20/B23 BZ bomblets packaged into CDU-9/B cluster adapters in an SUU-13( )/A dispenser. Known variants include:

CBU-17/A

The CBU-17/A practice cluster bomb consisted of 1200 BDU-34/B practice bomblets in an SUU-13/A dispenser.

CBU-18/A

The CBU-18/A anti-personnel cluster bomb consisted of an unknown number of BLU-25/B bomblets in an SUU-13A/A dispenser.

CBU-19/A

The CBU-19/A 60 kg (130 lb) non-lethal chemical warfare cluster bomb was identical to the U.S. Army's XM165 canister cluster subsystem. It consisted of a longitudinal strongback holding 16 dispenser modules, each of which contained 33 BLU-39/B23 CS bomblets (for a total of 528 bomblets).

Photo: U.S. Army
XM165 (CBU-19/A)
CBU-20/B

The CBU-20/B designation was possibly related to the development of the CBU-24/B, but no further details are available.

CBU-21/B

The CBU-21/B designation was possibly related to the development of the CBU-23/B, but no further details are available.

CBU-22/A

The CBU-22( )/A 113 kg (250 lb) class smoke cluster bomb consisted of 72 BLU-17/B smoke bomblets in an SUU-14( )/A dispenser. Known variants include:

CBU-23/B

The CBU-23/B anti-personnel/anti-material cluster bomb consisted of an unknown number of BLU-26/B fragmentation bomblets in an SUU-31/B dispenser.

CBU-24/B

The CBU-24( )/B anti-personnel/anti-material cluster bomb consisted of 665 BLU-26/B or BLU-36/B fragmentation bomblets in an SUU-30( )/B dispenser. Known variants include:

CBU-25/A

The CBU-25( )/A anti-personnel cluster bomb consisted of 132 BLU-24/B fragmentation bomblets in an SUU-14( )/A dispenser. Known variants include:

CBU-26/A

The CBU-26/A dummy cluster bomb consisted of 352 BDU-37/B practice bombs in an SUU-10/A dispenser.

CBU-27/B

The CBU-27/B is described as an unfilled container, which could be filled with various types of submunitions (thus becoming a CDU cluster adapter unit), and loaded into several types of standard dispensers. If this is indeed correct, then the use of the "CBU" nomenclature for this container was very unusual. The name "Hayes Container" has also been used in connection with the CBU-27/B in the context of chemical/biological warfare munitions, but further details about this "Hayes Container" are not available.

CBU-28/A

The CBU-28/A anti-personnel mine cluster bomb consisted of 4800 BLU-43/B "Short Dragontooth" minelets (in 40 CDU-2/B cluster adapters of 120 mines each) in an SUU-13/A dispenser.

CBU-29/B

The CBU-29( )/B 380 kg (840 lb) anti-personnel/anti-material cluster bomb consisted of 670 BLU-36/B fragmentation bomblets in an SUU-30( )/B dispenser. Known variants include:

CBU-30/A

The CBU-30/A 340 kg (750 lb) class non-lethal chemical warfare cluster bomb consisted of 1280 BLU-39/B CS bomblets (in 40 CDU-12/B cluster adapters of 32 bomblets each) in an SUU-13/A dispenser.

(31) (No information)
CBU-32

The CBU-32 (the full designation, either CBU-32/A or -32/B, is not available) was a wide-area mine cluster bomb. No further details are available.

CBU-33/A

The CBU-33/A 350 kg (770 lb) anti-tank mine cluster bomb consisted of 30 BLU-45/B shaped-charge minelets in an SUU-36/A dispenser.

CBU-34/A

The CBU-34/A anti-personnel mine cluster bomb consisted of 540 BLU-42/B WAAPM (Wide-Area Anti-Personnel Mine) fragmentation minelets (10 CDU-18/B or CDU-19/B clusters of 54 mines each) in an SUU-38/A dispenser.

(35...36) (No information)
CBU-37/A

The CBU-37/A anti-personnel mine cluster bomb consisted of 4800 BLU-44/B "Long Dragontooth" minelets (in 40 CDU-3/B cluster adapters of 120 mines each) in an SUU-13/A dispenser.

CBU-38/A

The CBU-38( )/A anti-personnel cluster bomb consisted of 40 BLU-49( )/B fragmentation bomblets in an SUU-13( )/A dispenser. Known variants include:

No information about the components of the CBU-38A/A, -38B/A and -38C/A is available. These designations probably referred to variants using the SUU-13A/A through -13C/A dispensers, but could also cover modified versions of the BLU-49/B submunition.

CBU-39/A
CBU-40/A

The CBU-39/A and CBU-40/A were cluster bombs consisting of an SUU-41( )/A dispenser filled with "Gravel" anti-personnel mines. An SUU-41( )/B dispenser contained 10 cluster adapters (CDU-4/B in the CBU-39/A, CDU-10/B in the CBU-40/A), each of which could store and release hundreds of mines. "Gravel" mines, also known as "button mines", consisted of a small bag of cloth, which was filled with a substance (mixture of RDX and lead azide for most variants) which would explode under pressure (e.g. when a person stepped on it). When stored in the cluster adapter, the mines were immersed in Freon coolant to keep them inert. The Freon would evaporate within a few minutes after release, thereby activating the mines. Some types of "Gravel" mines had a chemical neutralization system, which was designed to render the explosive filling inert after a certain amount of time. "Gravel" mines were produced in the 1968/70 time frame for use in Vietnam, but were only used on an experimental basis.

The following configurations of "Gravel" mines in SUU-41( )/A dispensers are known:

  • SUU-41/A with dummy mines
  • CBU-39/A (1500 XM41E1 anti-personnel mines (10 CDU-4/B clusters with 150 mines each) in SUU-41A/A)
  • CBU-40/A (6500 XM40E5 and 480 XM44 anti-intrusion mines (10 CDU-10/B clusters with 650 XM40E5 and 48 XM44 each) in SUU-41A/A)
  • 7500 XM40E5 anti-intrusion mines (10 CDU-5/B clusters with 750 mines each) in SUU-41A/A
  • 1500 XM65 anti-personnel mines (10 CDUs (possibly CDU-14/B) with 150 mines each) in SUU-41B/A
CBU-41/B

The CBU-41/B 220 kg (485 lb) cluster bomb consisted of 18 BLU-53/B incendiary bomblets in an SUU-51/B dispenser.

CBU-42/A

The CBU-42/A anti-personnel mine cluster bomb consisted of 540 BLU-54/B WAAPM (Wide-Area Anti-Personnel Mine) fragmentation minelets (10 CDU-20/B or CDU-21/B clusters of 54 mines each) in an SUU-38/A dispenser.

CBU-43/A

The CBU-43/A 380 kg (840 lb) cluster bomb consisted of an unknown number of BLU-48/B fragmentation bomblets packed into CDU-37/B cluster adapters in an SUU-37/A dispenser.

CBU-44/B

The CBU-44/B was an anti-personnel cluster bomb, about which no further details are available.

CBU-45/B

The CBU-45/B was a 450 kg (1000 lb) class anti-personnel/anti-material cluster bomb, about which no further details are available.

CBU-46/A

The CBU-46/A 400 kg (880 lb) anti-personnel cluster bomb consisted of 640 BLU-66/B or BLU-24/B fragmentation bomblets in an SUU-7C/A dispenser.

CBU-47/A

The CBU-47/A anti-personnel mine cluster bomb consisted of an unknown number of BLU-55/B minelets in an SUU-13/A dispenser.

(48) (No information)
CBU-49/B

The CBU-49( )/B 380 kg (840 lb) anti-personnel/anti-material cluster bomb consisted of 670 BLU-59/B fragmentation bomblets in an SUU-30( )/B dispenser. Known variants include:

CBU-50/A

The CBU-50/A cluster bomb consisted of 40 BLU-60/B fragmentation bomblets in an SUU-13/A dispenser.

CBU-51/A

The CBU-51/A cluster bomb consisted of 40 BLU-67/B cratering bomblets in an SUU-13/A dispenser.

CBU-52/B

The CBU-52( )/B 350 kg (770 lb) anti-material cluster bomb consisted of 217 BLU-61A/B fragmentation/incendiary bomblets in an SUU-30( )/B dispenser. Known variants include:

CBU-53/B
CBU-54/B

The CBU-53/B and CBU-54/B 370 kg (815 lb) anti-personnel/anti-material cluster bombs consisted of 670 incendiary bomblets (BLU-70/B in the CBU-53/B, BLU-68/B in the CBU-54/B) in an SUU-30B/B dispenser. Both clusters, which were presumably very similar, were tested in the 1968/69 time frame.

CBU-55/B

The CBU-55( )/B 210 kg (460 lb) cluster bomb consisted of three BLU-73A/B FAE (Fuel/Air Explosive) bombs in an SUU-49( )/B dispenser. Known variants include:

The CBU-72/B was identical to the CBU-55A/B except for the MK 339 MOD 0 fuze, which replaced the CBU-55A/B's FMU-83/B.

CBU-56

No reliable information about the CBU-56 is available. It may have been a cluster bomb using BLU-75/B fire bombs (about which no further data is available, either) as payload.

CBU-57/A

The CBU-57/A anti-personnel/anti-material cluster bomb consisted of 132 BLU-69/B incendiary bomblets in an SUU-14A/A dispenser.

CBU-58/B

The CBU-58( )/B 370 kg (815 lb) anti-personnel/anti-material cluster bomb consisted of 650 BLU-63( )/B fragmentation bomblets in an SUU-30A/B dispenser. Known variants include:

CBU-59/B

The CBU-59/B "Rockeye II" 347 kg (766 lb) anti-personnel/anti-material cluster bomb consisted of 717 BLU-77/B bomblets in a MK 7 MOD 3 dispenser. The CBU-59/B was the only USAF cluster bomb, which used a U.S. Navy MK 7 "Rockeye" series dispenser.

CBU-60/A

The CBU-60/A 345 kg (760 lb) anti-personnel cluster bomb consisted of 264 BLU-24/B fragmentation bomblets in an SUU-50/A dispenser.

CBU-61/B

The CBU-61/B was a chemical warfare cluster bomb filled with non-lethal CS gas bomblets. No information about the number and type of the submunition, or the dispenser model, is available.

CBU-62/B
CBU-63/B

The CBU-62/B and CBU-63/B were very similar 380 kg (840 lb) anti-personnel cluster bombs, which consisted of 2025 fragmentation bomblets in an SUU-30/B dispenser. The CBU-62/B was filled with M38 grenades, while the CBU-63/B used the M40A1. The M38 and M40 series fragmentation grenades were externally identical, and presumably differed in internal layout and/or fuzing.

Data for M38 and M40:
Diameter: 43 mm (1.7 in)
Weight: 136 g (0.3 lb)
Explosive: 27 g (0.06 lb) Composition B

Drawing, Photo: via ORDATA Online Website
M38 / M40 grenades
(64...65) (No information)
CBU-66/B

The CBU-66/B anti-vehicle mine cluster bomb was to consist of CDU-24/B canisters filled with BLU-81/B minelets in an SUU-51/B dispenser. However, the BLU-81/B mine was cancelled.

(67) (No information)
CBU-68/B

The CBU-68/B cluster bomb consisted of an unknown number of BLU-48/B fragmentation bomblets in an SUU-30/B dispenser.

(69) (No information)
CBU-70/B

The CBU-70/B anti-vehicle cluster bomb consisted of 79 BLU-85/B multi-linear shaped-charge bomblets in an SUU-30/B dispenser.

CBU-71/B

The CBU-71( )/B 370 kg (815 lb) anti-personnel/anti-material cluster bomb consisted of 670 BLU-86( )/B fragmentation bomblets in an SUU-30A/B dispenser. Known variants include:

CBU-72/B

The CBU-72/B 210 kg (460 lb) cluster bomb consisted of 3 BLU-73A/B FAE (Fuel/Air Explosive) bombs in an SUU-49A/B dispenser. It was identical to the CBU-55A/B, except for the MK 339 MOD 0 fuze, which replaced the CBU-55A/B's FMU-83/B.

(73) (No information)
CBU-74/B

The CBU-74/B anti-personnel cluster bomb consisted of 48 BLU-87/B fragmentation bomblets in an SUU-51B/B dispenser. When fitted with a KMU-422/B Paveway laser guidance kit, the CBU-74/B became the GBU-3/B guided bomb.

CBU-75/B

The CBU-75( )/B anti-personnel/anti-material cluster bomb consisted of BLU-63/B and/or BLU-86/B fragmentation bomblets in an SUU-54A/B dispenser. Known variants include:

The CBU-75( )/B was primarily developed as a payload for guided cluster bombs. When fitted with a KMU-421/B Paveway laser guidance kit, the CBU-75/B became the GBU-2/B PAVE STORM laser-guided cluster bomb. The CBU-75( )/B was also planned to be used in the GBU-15(V)/B MGWS (Modular Guided Weapon System), but this application (as GBU-15(V)3/B) was cancelled.

CBU-76/B

The CBU-76/B anti-material cluster bomb consisted of 290 BLU-61A/B incendiary/fragmentation bomblets in an SUU-51B/B dispenser. The SUU-51B/B was a dispenser for use with a KMU-422/B Paveway laser guidance kit, but there is no known GBU designation for a laser-guided CBU-76/B.

CBU-77/B

The CBU-77/B anti-personnel/anti-material cluster bomb consisted of 790 BLU-63/B fragmentation bomblets in an SUU-51B/B dispenser. The SUU-51B/B was a dispenser for use with a KMU-422/B Paveway laser guidance kit. The laser-guided CBU-77/B was possibly known as GBU-13/B, but this designation is unconfirmed and might be non-existing.

CBU-78/B

The CBU-78( )/B is the U.S. Navy version of the "Gator" area-denial cluster bomb. It consists of a mix of 45 BLU-91/B anti-tank and 15 BLU-92/B anti-personnel minelets in a MK 7 "Rockeye" or SUU-58/B dispenser. Known variants include:

The CBU-78/B, -78A/B and -78B/B differ in their fuzes and possibly other minor details.

CBU-79/B

No confirmed information about the CBU-79/B anti-personnel/anti-tank cluster bomb is available, but it was probably a U.S. Navy "Gator" cluster (similar to the CBU-78( )/B series) in the 900 kg (2000 lb) class (possibly using an SUU-54A/B dispenser). When fitted with a KMU-351/B Paveway laser guidance kit, the CBU-79/B became the GBU-6/B PAVE STORM laser-guided cluster bomb.

CBU-80/B

No details about the CBU-80/B cluster bomb are available. When fitted with a KMU-351/B Paveway laser guidance kit, it became the GBU-7/B PAVE STORM laser-guided cluster bomb. This appears to imply that the CBU-80/B used the same dispenser as the CBU-79/B.

CBU-81/A

The CBU-81/A cluster bomb consisted of 45 BLU-49A/B fragmentation bomblets in an unknown dispenser.

CBU-82/B
CBU-83/B

The CBU-82/B and CBU-83/B cluster bombs consisted of 60 BLU-91/B anti-tank (in the CBU-82/B) or BLU-92/B anti-personnel (in the CBU-83/B) minelets in an SUU-58/B dispenser. Both cluster bombs were used for test and evaluation purposes only.

CBU-84/B
CBU-85/B
CBU-86/B

The CBU-84/B, CBU-85/B and CBU-86/B cluster bombs consisted of an unknown number of BLU-91/B anti-tank and/or BLU-92/B anti-personnel minelets in an SUU-54A/B dispenser. The CBU-85/B contained only the BLU-91/B, the CBU-86/B only the BLU-92/B, and the CBU-84/B a mix of both. These cluster bombs were used for test and evaluation purposes only.

CBU-87/B

The CBU-87( )/B CEM (Combined Effects Munition) is a 430 kg (950 lb) multi-purpose cluster bomb, which consists of 202 BLU-97( )/B CEBs (Combined Effects Bomblets) in an SUU-65/B) dispenser. Known variants include:

No information about the difference between the CBU-87/B and -87A/B is available. Guided variants of the CBU-87( )/B are designated CBU-103/B and CBU-113/B.

CBU-88/B

The CBU-88/B "Smokeye" was a smoke cluster bomb, about which no confirmed details are available. Most likely, "Smokeye" was identical to the existing combination of 3 BLU-98/B bombs in an SUU-49A/B dispenser.

CBU-89/B

The CBU-89/B "Gator" is a 320 kg (700 lb) area-denial cluster bomb, which consists of a mix of 72 BLU-91/B anti-tank and 22 BLU-92/B anti-personnel minelets in an SUU-64/B dispenser. Known variants include:

No information about the difference between the CBU-89/B and -89A/B is available. Guided variants of the CBU-89( )/B are designated CBU-104/B.

CBU-90/B

The CBU-90/B ACM (Anti-Armor Cluster Munition) consisted of an unknown number of BLU-99/B bomblets in an SUU-65/B dispenser. The ACM was not produced.

(91) (No information)
CBU-92/B

The CBU-92/B ERAM (Extended-Range Anti-Armor Munition) was a 430 kg (950 lb) anti-tank cluster bomb, which consisted of 9 BLU-101/B and 3 area-denial submunitions (type unknown) in an SUU-65/B dispenser. The ERAM program was cancelled in 1987.

(93) (No information)
CBU-94/B

The CBU-94/B anti power-supply cluster bomb (a.k.a. "Blackout Bomb") consists of 202 BLU-114/B bomblets in an SUU-66/B dispenser. This configuration is identical to that of the CBU-102/B, but no information about differences is available. It's also possible that one of the two designations has been cancelled.

(95...96) (No information)
CBU-97/B

The CBU-97( )/B SFW (Sensor-Fuzed Weapon) is a 416 kg (914 lb) anti-armour cluster bomb, which consists of 10 BLU-108( )/B submunitions in an SUU-66/B dispenser. Known variants include:

Guided variants of the SFW are designated CBU-105/B and CBU-115/B.

CBU-98/B

The CBU-98/B DAACM (Direct Airfield Attack Combined Minition) was a 385 kg (850 lb) anti-airfield cluster bomb, which consisted of 8 BLU-106/B BKEP (Boosted Kinetic Energy Penetrator) projectiles and 24 British HB876 mines in an SUU-64/B dispenser. The BLU-106/B, and therefore also the CBU-98/B, was cancelled.

CBU-99/B

The CBU-99( )/B "Rockeye II" anti-tank cluster bomb consists of 247 MK 118 MOD 0 bomblets in an SUU-75( )/B dispenser. Known variants include:

  • CBU-99/B: 247 MK 118 MOD 0 submunitions in SUU-75/B
  • CBU-99A/B: 247 MK 118 MOD 0 submunitions in SUU-75A/B
  • CBU-99B/B: 247 MK 118 MOD 0 submunitions in SUU-75B/B

The CBU-99( )/B series is very similar to the older MK 20 "Rockeye II" series and the CBU-100( )/B, and details about differences are unclear.

Photo: via ORDATA Online Website
Bomb MK 118 MOD 0

The MK 118 bomb is a fin-stabilized anti-tank bomblet with a shaped-charge warhead and an impact-activated fuzing system. If the bomb strikes a hard target, the shaped charged warhead is detonated immediately. On a softer target, the detonation is delayed to allow some penetration of the warhead.

Data for MK 118 MOD 0:
Length: 34.3 cm (13.5 in)
Diameter: Body: 53 mm (2.1 in); fin assembly: 57 mm (2.25 in)
Weight: 590 g (1.3 lb)
Explosive: 170 g (0.37 lb) Octol

Drawing: via ORDATA Online Website
Bomb MK 118 MOD 0
CBU-100/B

The CBU-100( )/B "Rockeye II" anti-tank cluster bomb consists of 247 MK 118 MOD 0 bomblets in an SUU-76( )/B dispenser. Known variants include:

  • CBU-100/B: 247 MK 118 MOD 0 submunitions in SUU-76/B
  • CBU-100A/B: 247 MK 118 MOD 0 submunitions in SUU-76A/B
  • CBU-100B/B: 247 MK 118 MOD 0 submunitions in SUU-76B/B

The CBU-100( )/B series is very similar to the older MK 20 "Rockeye II" series and the CBU-99( )/B, and details about differences are unclear.

(101) (No information)
CBU-102/B

The CBU-102/B anti power-supply cluster bomb (a.k.a. "Blackout Bomb") consists of 202 BLU-114/B bomblets in an SUU-66/B dispenser. This configuration is identical to that of the CBU-94/B, but no information about differences is available. It's also possible that one of the two designations has been cancelled.

CBU-103/B

The CBU-103( )/B is the CBU-87/B CEM (Combined Effects Munition) fitted with a WCMD (Wind Corrected Munitions Dispenser) guidance kit. Known variants are:

  • CBU-103/B: 202 BLU-97/B in SUU-65/B (= CBU-87/B) + WCMD (Wind Corrected Munitions Dispenser) tail kit
  • CBU-103A/B: 202 BLU-97/B in SUU-65/B (= CBU-87A/B) + WCMD (Wind Corrected Munitions Dispenser) tail kit
  • CBU-103B/B: 202 BLU-97A/B in SUU-65/B (= CBU-87B/B) + WCMD (Wind Corrected Munitions Dispenser) tail kit

When fitted with a WCMD-ER (WCMD - Extended Range) kit, the weapon is known as CBU-113/B.

CBU-104/B

The CBU-104( )/B is the CBU-89( )/B "Gator" fitted with a WCMD (Wind Corrected Munitions Dispenser) guidance kit. Known variants are:

CBU-105/B

The CBU-105( )/B is the CBU-97( )/B SFW (Sensor Fzued Weapon) fitted with a WCMD (Wind Corrected Munitions Dispenser) guidance kit. Known variants are:

When fitted with a WCMD-ER (WCMD - Extended Range) kit, the weapon is known as CBU-115/B.

(106) (No information)
CBU-107/B

The 450 kg (1000 lb) class CBU-107/B PAW (Passive Attack Weapon) consists of 3750 non-explosive penetrator rods in a SUU-66/B dispenser with a WCMD (Wind Corrected Munitions Dispenser) guidance kit. It is used to destroy structures without a blast effect, which is intended to reduce colleteral damage.

(108...112) (No information; most likely not yet assigned)
CBU-113/B

The CBU-113/B is the CBU-87/B CEM (Combined Effects Munition) fitted with a WCMD-ER (Wind Corrected Munitions Dispenser - Extended Range) guidance kit.

(114) (Most likely reserved for CBU-89/B + WCMD-ER)
CBU-115/B

The CBU-115/B is the CBU-97B/B SFW (Sensor Fzued Weapon) fitted with a WCMD-ER (Wind Corrected Munitions Dispenser - Extended Range) guidance kit.

CBU-116/B

The CBU-116/B consists of 202 BLU-114/B bomblets in an SUU-65/B dispenser.

CBU-117/B
CBU-118/B

The CBU-118/B consists of 202 BLU-114/B bomblets in an SUU-65/B dispenser fitted with a WCMD (Wind Corrected Munitions Dispenser) guidance kit.

CCU/CCK - Cartridges

CCU-1/B Bomb Ejection Cartridge
(2) (No information)
CCU-3/A Impulse Cartridge
CCU-4/A Delay Cartridge
(5...8) (No information)
CCU-9/B Bomb Ejection Cartridge
CCU-10/B Bomb Ejection Cartridge
CCU-11/B Impulse Cartridge
(12) (No information)
CCU-13/B Impulse Cartridge
(14...15) (No information)
CCU-16/B Impulse Cartridge
CCU-17/B Delay Cartridge
CCU-18/B Delay Cartridge
CCU-19/B Delay Cartridge
CCU-20/A Percussion Primer
CCU-21/A Percussion Primer
CCU-22/A Impulse Cartridge
CCU-23/B Impulse Cartridge
(24...27) (No information)
CCU-28/A Impulse Cartridge
(29...32) (No information)
CCU-33/A Impulse Cartridge
(34...35) (No information)
CCU-36/A
CCU-37/A
CCU-38/A
(39) (No information)
CCU-40/A
CCU-41/B Flare/Decoy Ejection Impulse Cartridge; used in AN/ALE-50
CCU-42/A
CCU-43/B Impulse Cartridge
CCU-44/B Stores Ejection Impulse Cartridge
CCU-45/B Stores Ejection Impulse Cartridge
(46) (No information)
CCU-47/A
(48) (No information)
CCU-49/A
CCU-50/A
CCU-51/A
CCU-52/A Impulse Cartridge
(53) (No information)
CCU-54/A
CCU-55/A
CCU-56/A
(57) (No information)
CCU-58/A
CCU-59/A
(60) (No information)
CCU-61/A
(62) (No information)
CCU-63/B Flare Ejection Impulse Cartridge
CCU-64/B Explosive Actuator Firing Device
(65...67) (No information)
CCU-68/A Fire Extinguisher Cartridge
CCU-69/B Impulse Cartridge
(70) (No information)
CCU-71/A Impulse Cartridge
(72) (No information)
CCU-73/A
CCU-74/B Explosive Actuator Firing Device
(75...76) (No information)
CCK-77/E Launch Charge
(78...85) (No information)
CCU-86/A
CCU-87/A
CCU-88/A
CCU-89/B 20 Second Delay Cartridge
CCU-90/A Fire Extinguisher Cartridge
CCU-91/B Impulse Cartridge
CCU-92/A Electrical Cartridge
CCU-93/A Fire Extinguisher Cartridge
CCU-94/A Fire Extinguisher Cartridge
(95) (No information)
CCU-96/B Impulse Cartridge
(97...100) (No information)
CCU-101/A Drogue Deployment Impulse Cartridge; used with SJU-17/A
CCU-102/A Restraint Release Impulse Cartridge; used with SJU-17/A
(103...105) (No information)
CCU-106/B Flare/Chaff Ejection Impulse Cartridge
CCU-107/B Flare/Chaff Ejection Impulse Cartridge; used in SUU-25/A
(108) (No information)
CCU-109/A Impulse Cartridge
(110...111) (No information)
CCU-112/A Impulse Cartridge
CCU-113/A Aircraft Fire Extinguisher Cartridge
CCU-114/M Impulse Cartridge
(115...118) (No information)
CCU-119/A Impulse Cartridge
CCU-120/A Fire Extinguisher Cartridge
CCU-121/A Aircraft Fire Extinguisher Cartridge
CCU-122/A Fire Extinguisher Cartridge
CCU-123/E Impulse Cartridge
(124...125) (No information)
CCU-126/A Fire Extinguisher Cartridge
CCU-127/A Fire Extinguisher Cartridge
(128...131) (No information)
CCU-132/E Impulse Cartridge
CCU-133/A Initiator
(134...135) (No information)
CCU-136/A Countermeasures (Flare Ejection) Impulse Cartridge; used with AN/ALE-39, AN/ALE-47, AN/ALE-50
(137) (No information)
CCU-138/A Impulse Cartridge
(139...142) (No information)
CCU-143/A Impulse Cartridge
CCU-144/A Flare Ejection Cartridge; used with MJU-56/B
CCU-145/A Flare Ejection Cartridge; used with MJU-58/B
CCU-146/A Impulse Cartridge; used with JAU-57/A
CCU-147/A Aircraft Fire Extinguisher Cartridge
CCU-148/B Impulse Cartridge; used with MLU-57/B
CCU-149/A Impulse Cartridge
CCU-150/A Impulse Cartridge
CCU-151/A Impulse Cartridge
CCU-152/A Impulse Cartridge
CCU-153/A Impulse Cartridge
CCU-154/A Impulse Cartridge
CCU-155/A Impulse Cartridge
CCU-156/A Impulse Cartridge
CCU-157/A Impulse Cartridge
CCU-158/A Laser Initiated Detonator Cartridge
CCU-159/A Aircraft Fire Extinguisher Cartridge
(160...163) (No information)
CCU-164/A Impulse Cartridge
CCU-165/B Impulse Cartridge
CCU-166/B Impulse Cartridge
CCU-167/B Impulse Cartridge
CCU-168/B Impulse Cartridge
(169...170) (No information)
CCU-171/A Impulse Cartridge
CCU-172/A Impulse Cartridge
(173) (No information)
CCU-174/A Impulse Cartridge
CCU-175/A Impulse Cartridge
CCU-176/A Impulse Cartridge
CCU-177/A Impulse Cartridge
CCU-178/A Impulse Cartridge
CCU-179/A Impulse Cartridge
CCU-180/A Impulse Cartridge
CCU-181/A Impulse Cartridge
CCU-182/A Fire Extinguisher Cartridge
CCU-183/A Impulse Cartridge
CCU-184/A Fire Extinguisher Cartridge
CCU-185/A Impulse Cartridge

CDU - Clustering Devices

(1) (No information)
CDU-2/B Minelet Cluster; used in CBU-28/A (4800 BLU-43/B (40 CDU-2/B clusters of 120 mines each) in SUU-13/A)
CDU-3/B Minelet Cluster; used in CBU-37/A (4800 BLU-44/B (40 CDU-3/B clusters of 120 mines each) in SUU-13/A)
CDU-4/B Mine Canister; used in CBU-39/A (1500 XM41E1 anti-personnel mines (10 CDU-4/B clusters with 150 mines each) in SUU-41A/A)
CDU-5/B Mine Canister for XM40E5 mines; see CBU-39/A for details
(6...8) (No information)
CDU-9/B Bomblet Canister; used in
- CBU-16/A (40 CDU-9/B clusters of BLU-20/B23 in SUU-13/A)
- CBU-16A/A (40 CDU-9/B clusters of BLU-20/B23 in SUU-13A/A)
CDU-10/B Mine Canister; used in CBU-40/A (6500 XM40E5 and 480 XM44 anti-intrusion mines (10 CDU-10/B clusters with 650 XM40E5 and 48 XM44 each) in SUU-41A/A)
(11) (No information)
CDU-12/B Bomblet Cluster; used in CBU-30/A (1280 BLU-39/B (40 CDU-12/B clusters of 32 bomblets each) in SUU-13/A)
(13) (No information)
CDU-14/B Mine Canister for XM64 (or XM65??) mines
(15...17) (No information)
CDU-18/B Minelet Cluster; used in CBU-34/A (10 CDU-18/B or CDU-19/B clusters of 54 BLU-42/B in SUU-38/A)
CDU-19/B Minelet Cluster; used in CBU-34/A (10 CDU-18/B or CDU-19/B clusters of 54 BLU-42/B in SUU-38/A)
CDU-20/B Mine Canister; used in CBU-42/A (10 CDU-20/B or CDU-21/B clusters of 54 BLU-54/B in SUU-38/A)
CDU-21/B Mine Canister; used in CBU-42/A (10 CDU-20/B or CDU-21/B clusters of 54 BLU-54/B in SUU-38/A)
(22...23) (No information)
CDU-24/B Minelet Canister; intended for CBU-66/B (CDU-24/B canisters of BLU-81/B in SUU-51/B)
(25...36) (No information)
CDU-37/B Bomblet Cluster; used in CBU-43/A (CDU-37/B clusters of BLU-48/B in SUU-37/A)

CGU - Cargo Tiedown Items

CGU-1/B Cargo Tie-Down Nylon Strap
(2) (No information)
CGU-3/E Cargo Tie-Down Chain
CGU-4/E Cargo Tie-Down Chain

CHU - Cushions

(1...9) (No information)
CHU-10/P Arctic Clothing Cushion
CHU-11/P Arctic Clothing Cushion

CKU - Aircraft Ejection Seat Catapults

(1) (No information)
CKU-2/A Aircraft Ejection Seat Catapult
(3...4) (No information)
CKU-5/A Aircraft Ejection Seat Catapult; used in A-10, B-1B, B-2A, F-15, F-16, F-117
(6) (No information)
CKU-7/A Aircraft Ejection Seat Catapult; used in F-5, T-38
CKU-8/A Aircraft Ejection Seat Catapult; used in T-37
(9) (No information)
CKU-10/A Aircraft Ejection Seat Catapult
CKU-11/A Aircraft Ejection Seat Catapult

CLU - Calibrating Items

CLU-1/E Temparture Transmitter Testing Liquid Bath
(2) (No information)
CLU-3/E
CLU-4/E
(5...19) (No information)
CLU-20/E Nozzle Control Unit Gauge Set
(21...27) (No information)
CLU-28/E Nozzle Control Unit Gauge Set
(29...37) (No information)
CLU-38/E
(39...52) (No information)
CLU-53/A part of LGM-30G re-entry system (Mk.12A RV)
(54...55) (No information)
CLU-56/E Alignment Collimator Set
(57...58) (No information)
CLU-59/E part of/related to A/E24T-140
(60...80) (No information)
CLU-81/E Temparture Transmitter Testing Liquid Bath
CLG-82/E36T-2
CLG-83/E36T-2

CMU/CMK - Miscellaneous Clothing

CMU-1/P Ventilating Garment
CMU-2/P Rocket Fuel Handler's Coverall
CMU-3/P Coverall
CMU-4/P Rain Suit
CMK-5/P22P-1 Rocket Fuel Handler's Coverall
CMU-6/P Microwave Radiation Protection Coverall
(7) (No information)
CMU-8/P Personnel Rain Suit
(9) (No information)
CMU-10/P Anti-Exposure Hood
(11...20) (No information)
CMU-21/P22P-7 Survival Vest
(22) (No information)
CMU-23/P Survival Vest
CMU-24/P Survival Vest (CMU-23/P with strobe light)
(25...26) (No information)
CMK-27/P SAR Swimmer's Vest
(28) (No information)
CMU-29/P Chemical/Biological/Radiological Overvest
CMU-30/P22P-15 Survival Vest
(31...32) (No information)
CMU-33/P22P-18 Survival Vest

CNU/CNK - Containers

CNU-1/P Survival Kit Container
CNU-2/C Insulated Jug
(3...10) (No information)
CNK-11/P29S-1 Survival Kit Container
(12...13) (No information)
CNU-14/E
(15...32) (No information)
CNU-33/E
CNU-34/E
CNU-35/E used with LGM-30 missile components (?)
(36) (No information)
CNU-37/B Insulated Cargo Container
CNU-38/B Insulated Cargo Container
CNU-39/B Insulated Cargo Container
CNU-40/E Shipping and Storage Container
(41...42) (No information)
CNU-43/E Shipping and Storage Container; for the Minuteman II missile guidance and control system.
(44...67) (No information)
CNU-68/P Survival Kit Container; used with ejection seats
(69) (No information)
CNU-70/E Shipping and Storage Container
(71...74) (No information)
CNU-75/E45 Shipping & Storage Container for Chemical Dispenser
(76) (No information)
CNU-77/E23 Shipping & Storage Container
(78) (No information)
CNU-79/E Shipping & Storage Container for Bomb Dispenser
CNU-80/E25 Shipping & Storage Container for Bomb Dispenser
(81...88) (No information)
CNU-89/E Shipping & Storage Container for Spray Tank
(90...91) (No information)
CNU-92/E Shipping & Storage Container for SUU-30/B-based CBUs (including CBU-24/B, CBU-49/B, CBU-52/B, CBU-58/B, CBU-70/B, CBU-71/B)
(93...95) (No information)
CNU-96/C Carrying & Storage Container for Aircraft Illumination Signals
CNU-97/C Carrying & Storage Container for Aircraft Illumination Signals
CNU-98/E Shipping & Storage Container for Bomb Dispenser
(99) (No information)
CNU-100/E
(101...102) (No information)
CNU-103/E
CNU-104/E Container for CBU-33/A
(105...108) (No information)
CNU-109/E Shipping & Storage Container for BLU-52/B
(110) (No information)
CNU-111/P Survival Kit Container; used in ejection seat of F-4
(112...119) (No information)
CNU-120/E Container for CBU-55/B
(121...123) (No information)
CNU-124/E Shipping & Storage Container for AIM-54
CNU-125/E Container for AIM-7 Warhead
CNU-126/E Shipping & Storage Container for SUU-30/B-based CBUs (including CBU-24/B, CBU-49/B, CBU-52/B, CBU-58/B, CBU-70/B, CBU-71/B)
(127...128) (No information)
CNU-129/P Survival Kit Container; used with ejection seats
CNU-130/P Survival Kit Container
CNU-131/E Container for AGM-65
CNU-132/E Container; used with AGM-65
CNU-133/E
(134...146) (No information)
CNU-147/E Shipping & Storage Container for SUU-30/B-based CBUs (including CBU-24/B, CBU-49/B, CBU-52/B, CBU-58/B, CBU-70/B, CBU-71/B)
(148...149) (No information)
CNU-150/E Container for AGM-62 Wings & Fins
(151) (No information)
CNU-152/E Container; used with MAU-157/B
(153) (No information)
CNU-154/E Container for AGM-62
CNU-155/P Survival Kit Container
(156) (No information)
CNU-157/E Container for MK 13 MOD 0 Fire Bomb Initiator
(158) (No information)
CNU-159/E Shipping & Storage Container for AIM-54 Propulsion Section
(160...162) (No information)
CNU-163/E Missile Shipping & Storage Container
(164) (No information)
CNU-165/E Container; used with AIM-54
CNU-166/E Shipping & Storage Container for AIM/RIM-7 (without wings and fins)
CNU-167/E Container for AGM-45A/B
(168...170) (No information)
CNU-171/E Container for AGM-45A wing assemblies and tail fins
(172...178) (No information)
CNU-179/E Shipping & Storage Container for SUU-30/B-based CBUs (including CBU-24/B, CBU-49/B, CBU-52/B, CBU-58/B, CBU-70/B, CBU-71/B)
CNU-180/E Shipping & Storage Container for SUU-30/B-based CBUs (including CBU-24/B, CBU-49/B, CBU-52/B, CBU-58/B, CBU-70/B, CBU-71/B)
(181...182) (No information)
CNU-183/E Container for AGM-78
(184...187) (No information)
CNU-188 Baggage Container; used with F-14, EA-6B
CNU-189/E Container for MK 13 MOD 0/1 Arming Device for AIM-9D/G/H
(190...198) (No information)
CNU-199/E Shipping & Storage Container for AIM/RIM-7 Wings and Fins
(200...202) (No information)
CNU-203/E
(204...207) (No information)
CNU-208/E Container for CBU-55/B, CBU-72/B
(209...212) (No information)
CNU-213/E Shipping and Storage Container
(214...217) (No information)
CNU-218/E
(219...221) (No information)
CNU-222/E
(223) (No information)
CNU-224/E Storage Container; used with AIM-7
(225...232) (No information)
CNU-233/E Container; used with AIM-54
CNU-234/E Container for AIM-54A Guidance Section
(235...237) (No information)
CNU-238/E Container for CBU-55A/B, CBU-59/B, CBU-72/B, CBU-99/B, CBU-100/B
CNU-239/E Storage Overpack for AN/SSQ-62 Sonobuoys
CNU-240/E Container for AIM/RIM-7 Guidance and Control Section
CNU-241/E Container for AIM-54A Warhead Section
CNU-242/E Shipping & Storage Container for AIM-54C
CNU-243/E Container for AIM/RIM-7 Guidance and Control Section
CNU-244/E Container for AIM/RIM-7 Rocket Motor
CNU-245/E
CNU-246/E
CNU-247/E
CNU-248/E Container for WPU-5/B
CNU-249/E Cable Assembly Case
(250...255) (No information)
CNU-256/E Container; used with AGM-84
CNU-257/E Container; used with AGM-84
(258...262) (No information)
CNU-263/E
(264...269) (No information)
CNU-270/E Shipping and Storage Container for GBU-15/B warhead
(271) (No information)
CNU-272/E Missile Shipping and Storage Container
(273) (No information)
CNU-274/E Container; used with AIM-9
(275...282) (No information)
CNU-283/E Container for AIM-9, AGM-122
(284...285) (No information)
CNU-286/E Container; used with AIM-9
CNU-287/E Container for AIM-9G/H/L (without wings and fins)
CNU-288/E Container for "Paveway" LGB Computer Control Group
CNU-289/E Container for MK 36 Rocket Motor
(290...294) (No information)
CNU-295/E Container for AGM-88A
CNU-296/E Container for AGM-88A Wings & Fins
(297...299) (No information)
CNU-300/E Container; used with AIM-9
(301...304) (No information)
CNU-305/E Container for AGM-45 (or AIM-7E/F??)
CNU-306/E Container for AGM-62 Wings and Fins
(307) (No information)
CNU-308/E Shipping & Storage Container for RGM/UGM-109
CNU-309/E Container for PGU-14/B
(310...312) (No information)
CNU-313/E Multi-Purpose Pallet Crate
(314...315) (No information)
CNU-316/E Container; used with AGM-88
CNU-317/E Container for MAU-169A/B
(318) (No information)
CNU-319/E Comflicting references:
- Container for MK 20 "Rockeye II" CBU - Container for AIM-9
CNK-320/E24M-30 Cable Case
(321...324) (No information)
CNU-325/E
CNU-326/E Container for AGM-45 (or AIM-7E/F??)
CNU-327/E
(328...331) (No information)
CNU-332/E Container for 30mm Ammunition
CNU-333/E Container for BGM-71
(334) (No information)
CNU-335/E Container for BSU-49/B
CNU-336/E Container for BSU-50/B
(337...338) (No information)
CNU-339/E Shipping and Storage Container
CNU-340/E Shipping and Storage Container
(341...350) (No information)
CNU-351/E Container; used with AGM-88
CNU-352/E Container; used with AGM-88
CNU-353/E Container for AGM-88A Warhead Section
CNU-354/E Container for AGM-88A Rocket Motor
CNU-355/E Container for AGM-88
CNU-356/E Shipping & Storage Container for AGM-62
CNK-357/E24T-148 Cable Case for TTK-402/E24T-148
(358...360) (No information)
CNU-361/E F100 Shipping Case
CNU-362/E F100 Shipping Case
CNU-363/E F100 Shipping Case
CNU-364/E F100 Shipping Case
CNU-365/E F100 Shipping Case
(366...369) (No information)
CNU-370/E Container; used with AGM-88
CNU-371/E Container for WGU-39/B
CNU-372/E Container for BSG-82/B Airfoil Group
CNU-373/E Container for BSU-84/B Airfoil
(374...375) (No information)
CNU-376/E Container; used with AIM-54
CNU-377/E Container; used with AIM-54
(378) (No information)
CNU-379/E Container; used with AIM-7
CNU-380/E Container; used with AIM-7
CNU-381/E Container for BLU-107/B "Durandal"
(382...385) (No information)
CNU-386/E Container; used with AIM-54
(387) (No information)
CNU-388/E Container for BSU-80/B
(389...393) (No information)
CNU-394/E Container
(395...397) (No information)
CNU-398/E Shipping & Storage Container
CNU-399/E Shipping & Storage Container for AGM-65
(400...401) (No information)
CNU-402/E Container for AIM-120 Control Section
CNU-403/E Container for AIM-120 Warhead Section
(404) (No information)
CNU-405/E Container for 25mm Cartridge
(406) (No information)
CNU-407/E Shipping & Storage Container for AIM-7M
(408...410) (No information)
CNU-411/E Shipping & Storage Container for CBU-87/B, CBU-89/B, CBU-97/B, and SUU-30/B-based CBUs (including CBU-24/B, CBU-49/B, CBU-52/B, CBU-58/B, CBU-70/B, CBU-71/B)
(412...413) (No information)
CNU-414/E Engine Shipping Case
CNU-415/E Container for AIM-120A
(416) (No information)
CNU-417/E Container for BLU-109/B Casing
CNU-418/E
CNU-419/E Container for BSU-85/B
(420) (No information)
CNU-421/E
(422) (No information)
CNU-423/E Shipping & Storage Container for AGM-129
CNU-424/E Continer for AIM-120 Wings & Fins
(425...430) (No information)
CNU-431/E Container for AIM-120
CNU-432/E Shipping & Storage Container for AGM-136A
(433) (No information)
CNU-434/E Container for AGM-122A
CNU-435/E Container for AIM-9M
CNU-436/E Container for ADM-141A
(437) (No information)
CNU-438/E Container for AN/ALQ-190(V)1 Chaff Set
CNU-439/E Container for ADG-770/B Paveway Adapter Group
(440...442) (No information)
CNU-443/E Shipping & Storage Container for AGM-119B
(444) (No information)
CNU-445/E Shipping & Storage Container for AGM-65A/B/C/G
(446) (No information)
CNU-447/E Shipping & Storage Container for AGM-65E
CNU-448/E Shipping & Storage Container for AGM-114B/K
(449) (No information)
CNU-450/E Shipping & Storage Container for AGM-119B Canards
(451) (No information)
CNU-452/E Shipping & Storage Container for AIM-120 Wings & Fins
CNU-453/E Shipping and Storage Container
(454...455) (No information)
CNU-456/E Container for ADM-141
(457...458) (No information)
CNU-459/E Ku-Band Antenna Container
(460...462) (No information)
CNU-463/E Container for AIM-120 Guidance Section
CNU-464/E Container for AIM-120 Propulsion Section
(465...468) (No information)
CNU-469/E Container for "COMBAT TALON" Nose Radome
CNU-470/E X-Band Antenna Container
CNU-471/E Infrared Detection Set Container
CNU-472/E Shipping & Storage Container for AGM-65E (center/aft section)
CNU-473/E Shipping and Storage Container
CNU-474/E Shipping and Storage Container
CNU-475/E Container for LANTIRN
(476) (No information)
CNU-477/E Container; used with AGM-65
(478...482) (No information)
CNU-483/E Container for GBU-15(V)/B
(484...486) (No information)
CNU-487/E Container for RT-1489/ALE Expendable Decoy
CNU-488/E Compressed Cylinder Shipping & Storage Container; used with AGM-114
(489...490) (No information)
CNU-491/E Container for ADM-141A
CNU-492/E Container for GFK-11/A49E-10
CNU-493/E Container for GAK-14/A49E-10
(494) (No information)
CNU-495/E Container for AGM-84F/ATM-84F
CNU-496/E Shipping & Storage Container for AGM-142
(497...501) (No information)
CNU-502/E Container
(503) (No information)
CNU-504/E Shipping and Storage Container for AGM-142
CNU-505/E Container for MXU-650/B
(506...526) (No information)
CNU-527/E
(528...531) (No information)
CNU-532/E "Family of Munitions Container" Number 1; used for miscellaneous munitions items
CNU-533/E "Family of Munitions Container" Number 2; used for miscellaneous munitions items
CNU-534/E "Family of Munitions Container" Number 3; used for bomb fins
(535) (No information)
CNU-536/E Container for ADM-141B/C
(537) (No information)
CNU-538/E F-15 Canopy Container
(539) (No information)
CNU-540/E Shipping and Storage Container for AGM-142
(541...542) (No information)
CNU-543/E Container for MK 125 RATO Rocket
CNU-544/E Shipping and Storage Container
CNU-545/E Container for AIM-120 Warhead Section (WDU-33/B)
CNU-546/E Container for AIM-120 Control Section (WCU-11/B)
CNU-347/E Shipping and Storage Container
CNU-548/E Shipping and Storage Container
(549) (No information)
CNU-550/E Shipping and Storage Container
CNU-551/E Shipping and Storage Container
CNU-552/E AN/ALQ-155 Receiver/Transmitter Container
CNU-553/E Container; used with BGM-71
CNU-554/E Shipping & Storage Container for GBU-28/B
CNU-555/E Shipping & Storage Container for CATM-120
CNU-556/E Container for AGM-130 TV Guidance Section
(557...562) (No information)
CNU-563/E
(564...570) (No information)
CNU-571/E Container for BDU-57/B
CNU-572/E
(573) (No information)
CNU-574/E Signal Kit Shipping & Storage Container
CNU-575/E Container for AGM-154
(576...581) (No information)
CNU-582/E ATCOM Shipping & Storage Container
CNU-583/E ATCOM Shipping & Storage Container
CNU-584/E ATCOM Shipping & Storage Container
CNU-585/E ATCOM Shipping & Storage Container
CNU-586/E Shipping & Storage Container
CNU-587/E Shipping & Storage Container
CNU-588/E Shipping & Storage Container
CNU-589/E Container for KMU-556/B, KMU-557/B, KMU-558/B, KMU-559/B
(590) (No information)
CNU-591/E Shipping and Storage Container
(592...593) (No information)
CNU-594/E Shipping & Storage Container for C-17 crash recovery airbags
CNU-595/E Container for AGM-84H
(596...601) (No information)
CNU-602/E Collapsible Sonobuoy Container; used with AN/SSQ-110 sonobuoys
(603...604) (No information)
CNU-605/E Container for components of AN/ALQ-172
CNU-606/E Container for components of AN/ALQ-172
CNU-607/E Container for components of AN/ALQ-172
CNU-608/E Container for components of AN/ALQ-172
CNU-609/E Container for AIM-9X
(610...616) (No information)
CNU-617/E Shipping and Storage Container
(618...636) (No information)
CNU-637/E Shipping and Storage Container
CNU-638/E Shipping and Storage Container for AGM-142
CNU-639/E Shipping and Storage Container
CNU-640/E Shipping and Storage Container for AGM-142 Seeker Section
CNU-641/E Shipping and Storage Container for AGM-142 Data Link
CNU-642/E Shipping and Storage Container for AGM-142 Seeker Section
(643) (No information)
CNU-644/E Container for AIM-9X
CNU-645/E Container for AIM-9X (wings & fins)
(646...658) (No information)
CNU-659/E Shipping and Storage Container
(660...662) (No information)
CNU-663/E Shipping and Storage Container
CNU-664/E Container for "-368 toolkit" for F-15
CNU-665/E Container for "-468 toolkit" for F-15
CNU-666/E Container for "-768 toolkit (Detail A)" for F-15
CNU-667/E Container for "-768 toolkit (Detail C)" for F-15
CNU-668/E Container for "-768 toolkit (Detail F)" for F-15
CNU-669/E Container for "-768 toolkit (Detail J)" for F-15
CNU-670/E Container for "-268 toolkit" for F-15
(671...672) (No information)
CNU-673/E Shipping & Storage Container for AN/AWW-13
CNU-674/E Container for C-17 radome
CNU-675/E Container for C-17 OBIGGS (Onboard Inert Gas Generating System} winch
CNU-676/E Container for C-17 HUD
CNU-677/E Container for C-17 MLG (Main Landing Gear??) post
(678...679) (No information)
CNU-680/E Container for B-52 radome
CNU-681/E Container for CBT II nose radome
CNU-682/E Container for AN/APQ-122 antenna

CPU/CPK - Computers

(1...3) (No information)
CPU-4/A Flight Director Computer
(5...25) (No information)
CPU-26/P Air Navigation Computer
CPU-27/A Flight Director Computer
(28...29) (No information)
CPK-30/A24G-12 Air Data Computer
(31) (No information)
CPU-32/P
CPU-33/P
CPU-34/P
(35...36) (No information)
CPU-37/P
(38...42) (No information)
CPU-43/A Central Air Data Computer
(44...45) (No information)
CPU-46/A Altitude Encoding Transducer/Computer; used in F-101B/F (CPU-46/A-1), F-4 (CPU-46/A-2), T-38 (CPU-46/A-3), F-5B (CPU-46/A-3), F/TF-102 (CPU-46/A-7), F-104A/B/C/D (CPU-46/A-10), F-100C/D/F (CPU-46/A-11), RF-101A/C (CPU-46/A-13), VC-137B (CPU-46/A-15), VC-137C (CPU-46/A-16), F-8D/E (CPU-46/A-21), RF/F-8G/H/J/K/L (CPU-46/A-22), T-39A (CPU-46/A-26), T/DT-33A (CPU-46/A-27), B/RB-57A (CPU-46/A-27), RB-57D/F (CPU-46/A-27), C/VC-140 (CPU-46/A-28), B/RB-66 (CPU-46/A-30), B/RB-57B/C/E (CPU-46/A-32), B-57G (CPU-46/A-39)
(47...49) (No information)
CPU-50/P Navigational Computer
CPU-51/P
CPU-52/P
CPU-53/P Landing & Takeoff Computer; used in B-52B/C/D/E
CPU-54/P
CPU-55/P
(56...64) (No information)
CPU-65/A Flight Director Computer
CPU-66/A Altitude Encoding Computer; used in B-52 (CPU-66/A-1), C/KC-135 (CPU-66/A-1), RC-135A (CPU-66/A-1), WC-135B (CPU-66/A-1), EC-135A/C/G/H/J/K/L/P (CPU-66/A-1), RC-135C (CPU-66/A-2), A-4C (CPU-66/A-22), TA-4F (CPU-66/A-22), T-2B/C (CPU-66/A-24), A-4F (CPU-66/A-25), TF-9J (CPU-66/A-27)
(67) (No information)
CPK-68/A24G-23 Air Data Computer
CPK-69/A24G-24 Air Data Computer
(70) (No information)
CPK-71/A24G-25 Air Data Computer
(72) (No information)
CPU-73/P Attack Computer
(74...75) (No information)
CPU-76/A Flight Director Computer
CPK-77/A24G-28 Air Data Computer
(78...79) (No information)
CPU-80/A Flight Director Computer
CPU-81/A Stall Warning Computer
CPU-82/A Flight Director Computer
(83...91) (No information)
CPK-92/A24G-34 Flight Data Computer; used in F-4
(93) (No information)
CPU-94/P Take-Off Distance(?) Comnputer
(95...100) (No information)
CPU-101/B Missile/Bomb Guidance Computer
CPU-102/P
(103) (No information)
CPU-104/A True Airspeed Computer
(105...109) (No information)
CPU-110/A Rotation and Go-Around Computer
CPU-111/A Central Air Data Computer
(112...114) (No information)
CPU-115/A Angle-of-Attack Computer
(116...122) (No information)
CPU-123/B Computer in MAU-169/B "Paveway II" control group
(124...126) (No information)
CPU-127/P
(128) (No information)
CPU-129/A Flight Director Computer; used in F-5E
(130) (No information)
CPK-131/A37G-13 Digital Avionics Processor; used in BQM-74C
(132) (No information)
CPU-133/A AFCS (Aircraft Flight Control System) Digital Computer; used in SH-60B
CPK-134/A37U-34
CPK-135/A37U-34 Backup Automatic Flight Control System Computer
CPU-136/A Air Data Computer
CPK-137/A24J-23 Fuel Savings Advisory Computer
CPK-138/A37U-35 Air Data Computer
CPK-139/A37U-35 Flight Control Processor; used in KC-135R
CPU-140/A Standard Central Air Data Computer; used in E-2C, EA-6B, C-2A
CPU-141/A Standard Central Air Data Computer (SCADC); used in C-130
CPU-142/A Standard Central Air Data Computer (SCADC)
CPU-143/A Digital Air Data Computer; manufactured by GEC; used in F-4F
CPK-144/A24J-24 Fuel Savings Advisory Computer
(145) (No information)
CPK-146/A24J-24 Fuel Management Computer
(147...148) (No information)
CPU-149/B Guidance Electronics Unit of WGU-12/B
(150...151) (No information)
CPU-152/A Standard Central Air Data Computer; used in S-3
(153...156) (No information)
CPU-157/B Guidance Electronics Unit of WGU-12/B
CPU-158/B
(159...160) (No information)
CPU-161/A Flight Control Computer
(162) (No information)
CPU-163/A Air Data Computer
CPU-164/A Engine Computer
CPU-165/A Alarm Monitor Group; used in C-17
CPU-166/A Ground Proximity Warning Computer; used in C-17
(167...171) (No information)
CPU-172/A Flight Loads Data Recorder; manufactured by L-3; used in F-4
(173) (No information)
CPU-174/A
CPU-175/A Standard Central Air Data Computer; used in F-14
CPU-176/F Digital Computer System
(176...177) (No information)
CPK-178/A37G-16 Flight Control Processor
CPK-179/A37G-16 Spoil Control Computer
(180...184) (No information)
CPU-185/A Air Data Computer
CPU-186/B Seeker Signal Processor; used in GBU-24/B
CPU-187/A Air Data Computer
CPU-188/A Fuel Management Computer
CPU-189/B Guidance Section Receiver-Transmitter; used with GBU-24/B
CPU-190/B Guidance Section Receiver-Transmitter; used with WGU-39/B
CPU-191/A Air Data Computer
(192) (No information)
CPU-193/A24J-28 Fuel Savings Advisory Computer
CPU-194/A Air Data Computer
(195...202) (No information)
CPU-203/A Video Signal Processor
(204...205) (No information)
CPU-206/A Digital Signal Processor
(207) (No information)
CPU-208/A Electronic Components Assembly; used in AC-130U
CPU-209/A Signal Data Converter

CQU - Breathing Air Items

(1...6) (No information)
CQU-7/P Blower Assembly; part of AERP (Aircrew Eye/Respiratory Protection) System
CQK-8/P Ventilator Assembly; part of A/P22P-9
CQU-9/U HEED Air Servicing Cylinder
CQU-10/U Portable Compressed Air Refill System

CRU/CRK - Oxygen Items

(1...6) (No information)
CRU-7/P In-Line Diluter-Reducer Adapter
CRU-8/P Oxygen Mask to Regulator Connector
(9) (No information)
CRU-10/P Emergency Bailout Oxygen Cylinder
(11...17) (No information)
CRU-18/A On-Off Oxygen Valve
(19...20) (No information)
CRU-21/A Automatic Pressure Breathing Oxygen Regulator
(22) (No information)
CRU-23/A 10-Liter Liquid Oxygen Indicator System Dummy Converter
CRU-24/A 25-Liter Liquid Oxygen Indicator System Dummy Converter
(25) (No information)
CRU-26/P Partial Pressure Coveralls and Helmet Oxygen Regulator
CRK-27/P29S-1
CRU-28/P Partial Pressure Helmet to Regulator Connector
(29...33) (No information)
CRU-34/A Automatic Pressure Breathing Oxygen Regulator
(35...42) (No information)
CRU-43/A Oxygen Leads Connector; used with MBU-5/P
CRU-44/A Oxygen Regulator
CRK-45/P22S-2 Full Pressure Helmet Oxygen Regulator
CRK-46/P22S-2 Full Pressure Coverall Pressure Controller
CRU-47/A Oxygen Regulator
CRU-48/A Oxygen Regulator
CRU-49/A Oxygen Regulator
CRU-50/A Liquid Oxygen Conveter Fill/Buildup/Vent Valve
(51) (No information)
CRU-52/A Aircraft Panel-Mounted Low-Pressure Oxygen Regulator
CRK-53/P22P-1 Rocket Fuel Handler's Clothing Outfit Environmental Control Unit
CRU-54/A Aircraft Panel-Mounted Oxygen Regulator
CRU-55/A Aircraft Panel-Mounted Oxygen Regulator
(56) (No information)
CRU-57/A Aircraft Panel-Mounted Low-Pressure Oxygen Regulator
(58) (No information)
CRU-59/E Liquid Oxygen Filler Valve
CRU-60/P Oxygen Mask to Regulator Connector; manufactured by Gentex
(61...65) (No information)
CRU-66/A Diluter Demand Oxygen Regulator
(67) (No information)
CRU-68/A Panel-Mounted Automatic Pressure Demand Oxygen Regulator
CRU-69/A Panel-Mounted Automatic Pressure Demand Oxygen Regulator
(70...71) (No information)
CRU-72/A Aircraft Panel-Mounted High-Pressure Oxygen Regulator
CRU-73/A Automatic Pressure Breathing Oxygen Regulator; manufactured by Litton; used in A-10, B-52, C-130, C-141, E-8, F-5, F-16, T-38
CRU-74/P Chlorate-Candle Emergency Oxygen Supply
(75) (No information)
CRK-76/P22S-6 High-Altitude Flying Helmet Pressure Controller
CRK-77/P22S-6 High-Altitude Flying Helmet Oxygen Regulator
(78) (No information)
CRU-79/P Chest-Mounted Miniature Oxygen Breathing Regulator; manufactured by Litton; used with MBU-14/P
CRU-80/P Air Filter Pack; manufactured by Gentex
(81) (No information)
CRU-82/P Chest-Mounted Positive Pressure Oxygen Regulator; part of OBOGS (On-Board Oxygen Generating System); manufactured by Litton; used with MBU-14/P; used in AV-8B, F-14D, F/A-18C/D/E/F, T-45; replaced by CRU-103/P
CRU-83/A Polarographic Alarm Oxygen Monitor; part of OBOGS (On-Board Oxygen Generating System); used in AV-8B
(84...86) (No information)
CRU-87/U 10-Liter Patient Therapeutic Liquid Oxygen Converter
CRU-88/P Chest-Mounted Positive Pressure Oxygen Regulator; part of OBOGS (On-Board Oxygen Generating System); replaced by CRU-103/P
(89...90) (No information)
CRU-91/A Polarographic Alarm Oxygen Monitor; part of OBOGS (On-Board Oxygen Generating System); used in AV-8B, F/A-18
CRU-92/A Oxygen Regulator (night-vision version of CRU-73/A); manufactured by Litton
CRU-93/A Oxygen Regulator "Combat Edge"; manufactured by Litton; used in F-16
CRU-94/P Integrated Terminal Block; manufactured by Gentex; part of "Combat Edge" system
CRU-95/P Oxygen Regulator (hardened version of CRU-82/P); manufactured by Litton
(96) (No information)
CRU-97/A Demand Oxygen Regulator
CRU-98/A Oxygen Regulator "Combat Edge"; manufactured by Litton; used in F-15
CRU-99/A SSOM (Solid State Oxygen Monitor); manufactured by Litton; part of OBOGS (On-Board Oxygen Generating System); used in AV-8B, F-14D, F/A-18C/D/E/F, T-45
(100...102) (No information)
CRU-103/P G-Compensated Oxygen Regulator; manufactured by Carleton Technologies; part of OBOGS (On-Board Oxygen Generating System) and A/P22P-16; used with MBU-24/P; replacement for CRU-79/P, CRU-82/P, CRU-88/P
(104...118) (No information)
CRU-119/A Aircraft Oxygen Monitor; used in F-16C
CRU-120/A Connector Regulated Aircraft Breathing Regulator; used in F-16C
(121) (No information)
CRU-122/P Demand Oxygen Regulator

CSU/CSK - Special Clothing

(1) (No information)
CSU-2/P Partial Pressure Suit
CSU-3/P Anit-G Garment
CSU-4/P Partial Pressure Suit
CSU-5/P Partial Pressure Suit (modified CSU-4/P)
CSK-6/P22S-2 High Altitude Coverall
CSU-7/P High Altitude Coverall
(8...10) (No information)
CSU-11/P Anti-G Garment
CSU-12/P Anti-G Garment
CSU-13/P Anti-G Garment
CSU-14/P Anti-G Garment
CSU-15/P Anti-G Garment
(16) (No information)
CSU-17/P Counter Pressure Vest; part of A/P22P-16
(18...19) (No information)
CSU-20/P22P-16 Anti-G Garment
CSU-21/P Counter Pressure Vest
CSU-22/P Anti-G Trousers
CSU-23/P Anti-G Trousers

CTU - Aerial Delivery Containers

CTU-1/A Parachute-Retarded High-Speed Aerial Delivery Container
CTU-2/A Parachute-Retarded High-Speed Aerial Delivery Container

CVU/CVK - Covers

(1...52) (No information)
CVK-53/F42P-1
(54...70) (No information)
CVK-71/F42P-1
(72...76) (No information)
CVK-77/F42P-1
CVK-78/F42P-1
(79...111) (No information)
CVU-112/E Umbilical Receptacle Protective Cover; used with AGM-69A missile on MHU-69A/E
(113...129) (No information)
CVK-130/F42P-1
CVK-131/F42P-1
CVK-132/F42P-1
(133) (No information)
CVU-134/E Guided Missile Components Cover Set; used with AGM-86 & AGM-129
CVU-135/E Guided Missile Protective Cover; used with AGM-86B
(136...137) (No information)
CVU-138/E Shipping and Storage Container Cover
(139...142) (No information)
CVU-143/E Umbilical Receptacle Cover; used with AGM-86 & AGM-129
(144...156) (No information)
CVU-157/E
(158...162) (No information)
CVU-163/E Electrical Cap Set; used with AGM-129
CVU-164/E Ultralight Camouflage Screen (Snow/Partial Snow)
CVU-165/E Ultralight Camouflage Screen (Asphalt/Concrete)
CVU-166/E Ultralight Camouflage Screen (Green/Tan)
(167...168) (No information)
CVU-169/E Sensor Lens Protective Cover; used with AGM-129
(170...171) (No information)
CVU-172/E Generator Protective Cover; used with AGM-129
CVU-173/E Aircraft Ground Servicing Shield
CVU-174/E Aircraft Ground Servicing Shield
CVU-175/E Aircraft Ground Servicing Shield
CVU-176/E Aircraft Ground Servicing Shield
CVU-177/E Aircraft Ground Servicing Shield
CVU-178/E Aircraft Ground Servicing Shield
CVU-179/E Aircraft Ground Servicing Shield
(180...181) (No information)
CVU-182/A Guided Missile Protective Cover; used with AGM-65
(183) (No information)
CVU-184/E
(185...188) (No information)
CVU-189/E Aircraft Ground Servicing Shield
(190...194) (No information)
CVU-195/A Electrical Load Dummy Cover; used with LAU-128/A

CWU - Warmth Clothing

CWU-1/P Flying Coverall
CWU-2/P Intermediate Flying Coverall
CWU-3/P Anti-Exposure Flying Coverall
CWU-4/P Immersion Protection Garment; used with CSU-4/P
CWU-5/P Intermediate Cold Weather Trousers
CWU-6/P Extreme Cold Weather Insulated Trousers
CWU-7/P Cold Weather Jacket
CWU-8/P Extreme Cold Weather Parka
CWU-9/P Jacket and Trouser Liner
CWU-10/P Anti-Exposure Flying Coverall
(11) (No information)
CWU-12/P Anti-Exposure Flying Coverall
(13) (No information)
CWU-14/P Pararescue Suit Jacket
CWU-15/P Pararescue Trousers
CWU-16/P Quick Donning Anti-Exposure Flying Coverall
CWU-17/P Flyer's Winter Jacket
CWU-18/P Extreme Cold Weather Flyer's Trousers
(19...20) (No information)
CWU-21/P Anti-Exposure Flying Coverall
CWU-22/P Anti-Exposure Underwear
CWU-23/P Anti-Exposure Liner
(24...26) (No information)
CWU-27/P Flyer's Summer Coverall (Nomex Flight Suit); part of A/P22P-6
CWU-28/P Flight Suit
(29...32) (No information)
CWU-33/P Flyer's Anti-Exposure Fire-Resistant Coverall
(34...35) (No information)
CWU-36/P Flyer's Fire-Resistant Summer Jacket
(37...41) (No information)
CWU-42/P Flyer's High Temperature Resistant Summer Coverall
CWU-43/P Flyer's Anti-Exposure High Temperature Resistant Drawer; part of A/P22P-6
CWU-44/P Flyer's Anti-Exposure High Temperature Resistant Undershirt; part of A/P22P-6
CWU-45/P Cold Weather Flyer's Jacket
CWU-46/P Security Police's Cold Weather Jacket
CWU-47/P Air Police Jacket
CWU-48/P Flyer's High Temperature Resistant Coverall
CWU-49/P Women's Shirt
CWU-50/P Women's Jacket
CWU-51/P Women's Slacks
(52...53) (No information)
CWU-54/P Women's Slacks
CWU-55/P Women's Shirt
(56...58) (No information)
CWU-59/P
CWU-60/P Flyer's Quick-Donning Anti-Exposure Coverall
(61) (No information)
CWU-62/P Anti-Exposure Flyer's Coverall; part of A/P22P-6
CWU-63/P Detachable Jacket Collar
CWU-64/P Cold Weather Flyer's Suit
(65) (No information)
CWU-66/P IACC (Integrated Aircrew Chemical Coverall) Chemical Defense Flight Suit
CWU-67/P Flyer's Anti-Exposure Socks
(68...71) (No information)
CWU-72/P Flyer's Anti-Exposure Coverall Liner; part of A/P22P-6
CWU-73/P Flyer's Fire-Resistant Blue Summer Coverall
CWU-74/P Flyer's Anti-Exposure Coverall
CWU-75/P Flyer's Anti-Exposure Socks; part of A/P22P-6
(76) (No information)
CWU-77/P Aircrew Chemical Defense Coverall (similar to CWU-66/P)
(78) (No information)
CWU-79/P PAESS (Passenger Anti-Exposure Survival System) Coverall (modified CWU-62/P); part of A/P22P-7
CWU-80/P Aircrew Chemical Filter Pack
(81...82) (No information)
CWU-83/P PAESS (Passenger Anti-Exposure Survival System) Anti-Exposure Suit

CXU - Impact Marking Smoke Charges

CXU-1/B Spotting Charge
CXU-2/B Spotting Charge
CXU-3/B Practice Bomb Signal Cartridge; used in BDU-57/B
CXU-4/B Spotting Charge

[AxU] [BxU] [CxU] [DxU] [ExU] [FxU] [GxU] [HxU] [JxU] [KxU] [LxU] [MxU] [NxU] [PxU] [RxU] [SxU] [TxU] [VxU] [WxU]



Index of ASETDS Designation Listings

Back to Home page



Last Updated: 2 November 2024
